SPECIFICATION

Electrical Life: 10,000 cycles

Non-switching Rating: 100mA ,50V DC

Switching Rating: 25mA,24VDC

Contact Resistance : 100mΩ max.

Insulation Resistance: 100MΩ min( 500 VDC)

Dielectric Strength: 500V AC/1 minute

Circuit: 1P2T,1P3T

Operation Temperature Range:-10 to +60℃

Storage Temperature Range: -20 to +75℃
