SPECIFICATION

MECHANICAL

Operation Force:360± 90gf, Transparent (T), 69, 67,65

       260± 70gf Red (R), DTSJW – 69,67,65,64

      180± 50gf Brown (N), DTSJW – 69,67,65,64

      160 ± 50gf Brown (N), DTSJW – 66

      160 ± 50gf Silver (S), DTSJW – 68

Stop Strength: Max 3kgf vertical static load continuously for 15 seconds

Stroke: 0.25 +0.20 / - 0.1 mm 66N, 68S
            0.45±0.2mm, 69, 67, 65N(R) ,65T, 64N(R)
            0.6±0.2mm, 69, 67T

Operation Temperature: -25℃ to +70℃

Storage Temperature: -30℃ to + 80℃

ELECTRICAL

Electrical Life:500,000 cycles min. For 69N(R)(T), 67N(R)(T), 65N(R)(T),64N(R)

                       100,000 cycles min. for DTSJW-66N, 68S

Rating: 50mA, 12VDC

Contact Resistance: 100m? max.

Insulation Resistance: 100M? min. at 500VDC

Dielectric Strength: 250VAC/ minute

Contact Arrangement: 1 pole 1 throw

MATERIAL

COVER: Stainless steel

TERMINAL: Brass with silver plated

BASE: UL94V-0 Nylon High-Temp. Thermoplastic

Color: Black
