SPECIFICATION

MECHANICAL

Operation Force: 320±50gf Salmon(S)

                            160±50gf White(W)

Stroke: 0.25+0.1mm/-0.2mm

Operation Temperature: -25℃ to +70℃

Storage Temperature: -30℃ to +80℃

ELECTRICAL

Electrical Life: 50,000 cycles for 160g,320g

Rating:  50mA, 12VDC

Contact Resistance: 100m? max.

Insulation Resistance: 100M? min.500VDC

Dielectric Strength: 350VAC/1 minute

Contact Arrangement 1 pole 1 throw

MATERIAL

COVER: Nickel silver

BASE: UL94V-0 Nylon High- Thermoplastic

Color: Black

CONTACT: Stainless with silver cadding

TERMINAL: Brass with silver Plated

STEM: UL94V-0 Nylon High- Thermoplastic

Color: Samlmon(320gf),Brown(160gf)
